Cast iron pump body and support
motor with copper winding
brass impeller
stainless steel welded shaft
Max. suction: 8M
| Model | Voltage(V) | Best DC Voltage(V) | Power(W) | Max.Flow(m3/h) | Max. Head(M) | Outlet(inch) | Current(A) |
| SQDX1.5-25-24-300 | 24V | 17V-60V | 300 | 1.5 | 25 | 1'' | 12A |
| SQDX3.5-35-48-600 | 48V | 48V-100V | 600 | 3.5 | 35 | 1'' | 12A |
| SQDX10-10-24-300 | 24V | 17V-60V | 300 | 10 | 10 | 2'' | 12A |
| SQDX12-18-48-600 | 48V | 41V-96V | 600 | 12-14 | 18-20 | 2'' | 12A |
| SQDX16-30-110-1000 | 110V | 72V-150V | 1000 | 16 | 30 | 2'' | 8A |
| SQDX32-8-48-750 | 48V | 41V-96V | 750 | 32-36 | 8-10 | 3'' | 15A |
| SQDX40-11-72-1100 | 72V | 72V-150V | 1100 | 40 | 11 | 3'' | 15A |
| SQDX48-13-96-1200 | 96V | 72V-145V | 1200 | 48 | 13 | 4'' | 12A |
| SQDX52-14-110-1400 | 110V | 96V-200V | 1400 | 52 | 14 | 4'' | 12A |
