Cast iron pump body and support
motor with copper winding
brass impeller
stainless steel welded shaft
Max. suction: 8M
| Model | Voltage(V) | Best DC voltage(V) | Current(A) | Power(W) | Max. Flow(m3/h) | Max.Head(M) | Outlet(inch) | Max. Suction(M) |
| 1inch 24V | 24V | 17V-60V | 12A | 450 | 4.5 | 16 | 1'' | 8M |
| 1inch 48V | 48V-72V | 41V-96V | 12A | 600 | 6-6.5 | 24-32 | 1'' | 8M |
| 2inch 24V | 24V | 17V-60V | 12A | 450 | 14-16 | 7-11 | 2'' | 8M |
| 2inch 48V | 48V-72V | 41V-96V | 12A | 900 | 18-20 | 14-18 | 2'' | 8M |
| 3inch 48V | 48V-72V | 41V-96V | 12A | 1100 | 33-38 | 8-11 | 3'' | 8M |
